Crestron Flex All-in-One Videobar 70 for Zoom Rooms

The Crestron UC-SB2-CAM-A-Z is the Crestron Flex Videobar 70, a wall-mounted all-in-one conferencing bar built for medium to large meeting rooms running Zoom Rooms software. It integrates a quad-camera array, 24-microphone linear array, dual 10-watt speakers, and a certified Zoom Rooms compute engine into a single 38.58-inch bar.

Product Description

The UC-SB2-CAM-A-Z delivers a premium large-room conferencing experience without racks of separate components. The quad-camera configuration uses one 20-megapixel main camera plus three sub-cameras (left, center, right) to provide wide coverage and intelligent active speaker tracking across conference rooms up to 29.5 feet deep. The 24-element microphone linear array with adaptive beamforming, automatic gain control, and dynamic noise suppression ensures every voice is captured clearly regardless of seating position.

Audio output comes from dual 10W stereo speakers built directly into the bar. The Android-based compute platform running on the QCS8250 chipset comes with Zoom Rooms pre-installed. Connectivity includes dual-band Wi-Fi 6 (802.11ax), Bluetooth 5.2, dual 1G Ethernet ports, and multiple HDMI outputs for up to two 4K displays. Content ingest is available via the HDMI input on the bar itself or through wireless screen sharing.

Key Features

• Quad-camera array — 20MP main camera plus 3 sub-cameras with 14° overlap for full room coverage
• 7.5x digital autozoom with intelligent active speaker framing
• 24-microphone linear array with adaptive beamforming and AEC up to 29.5 ft (9 m)
• Dual 10W stereo speakers integrated into the bar
• Android OS on QCS8250 chipset with Zoom Rooms pre-installed
• Dual-band simultaneous Wi-Fi 6 (2x2 80 MHz) and Bluetooth 5.2
• Dual 1G Ethernet ports for redundant network connectivity
• Up to two 4K HDMI display outputs (third output reserved for future use)
• HDMI content ingest for wired BYOD or presentation sharing
• HDCP 1.4 and HDCP 2.2 content protection support
• XiO Cloud service compatible for remote monitoring and management
• Wall-mount via integrated bracket; optional tabletop kit (UC-SB2-TTK) and VESA display mount kit (UC-SB2-DMK) available separately
• Dimensions: 38.58 in. L × 4.33 in. H × 3.77 in. D; Weight: 13.2 lb

Typical Applications

• Medium and large conference rooms requiring a single-bar all-in-one Zoom Rooms solution
• Boardrooms and executive suites needing 4K dual-display output with intelligent camera tracking
• Training rooms and classrooms where wide-angle coverage of the full room is required
• Open-plan collaboration areas that benefit from a clean, wall-mounted form factor
• Organizations standardizing on Zoom Rooms with centralized XiO Cloud device management

Technical Specifications

Frequently Asked Questions

Does the UC-SB2-CAM-A-Z include a touch screen controller?

No — the Videobar 70 is the conferencing bar only. A Zoom Rooms touch controller (such as the Crestron Flex 7-inch touch screen) is required and sold separately.

How many displays does it support?

The UC-SB2-CAM-A-Z supports up to two 4K displays via its HDMI outputs. A third HDMI output is present but reserved for future use.

Can guests share content wirelessly?

Yes. The bar supports direct HDMI wired sharing and can be paired with a Crestron AirMedia solution for wireless content sharing from laptops and mobile devices.

Does it support BYOD (Bring Your Own Device) conferencing?

Yes. BYOD is supported via local HDMI and USB-C connection to the bar, or via a DM Essentials TXU/RXU pair or AirMedia 3 solution for single USB-C connectivity.

Where can I purchase the UC-SB2-CAM-A-Z?

The UC-SB2-CAM-A-Z is available at Creation Networks, an authorized Crestron dealer.
